Big Blue Fringe

Discussion

10 replies
Posted by Pete D on March 2, 2010 at 6:33 PM
Big Blue Fringe
Wow.

This is really cropped into the frame, but still, I don't think I've ever seen such a nasty example of blue fringing.

The "remove blue fringe" in Camera Raw seems to have no effect on this. How would you fix such a thing?

Pete D.

This was taken with a 500 mm lens at f/5.6, ISO 400, 1/500s

Posted by Harley Goldman on March 2, 2010 at 6:39 PM
Try masking the area and desaturating the blue?
Posted by David Bostedo on March 2, 2010 at 8:21 PM
You can try desaturating without masking.... use the Hue/Saturation tool set to "Blue". Then select the eye dropper in that tool and click the fringe. Move the saturation slider down, and it should get better. It might require some cleanup for sharpness, and if there's the same color anywhere else in the image you might still have to mask things. But it's a start.
Posted by Bob Steele on March 2, 2010 at 8:51 PM
Try the HSL/Grayscale tab in Camera Raw, Saturation sub-tab, pull the purples and blues down. It worked on your crop, should work even better on the RAW file.
Posted by Keith Bauer on March 2, 2010 at 9:26 PM
As suggested by David above.... Add a Hue Saturation adjustment layer, then select the blues. Move the Saturation slider all the way to the left. Here's the result.....
Posted by Pete D on March 2, 2010 at 10:09 PM
Thank you. It works like a charm for this one because there isn't much actual blue in the image.

Pete D.
Posted by Linnet Long on March 4, 2010 at 12:32 AM
His nose, mouth, and the nut have lost some detail, though - and color. What is that due to?
Posted by David Bostedo on March 4, 2010 at 9:00 AM
Linnet - If you're talking about the edges, the fringing was just desaturated to make it less apparent; It's still there, which is the cause of the fuzziness. If you're talking about the overall detail, there probably was some amount of the same blue in other areas. It may even have been a bit of noise in the shadows, that the deasaturation got rid of. Noise can add "apparent sharpness" to an image, because your eye perceives detail that may or may not actually be there due to noise. In some cases, noise-less images can actually look odd, and I know people that add a little noise to big prints to simulate detail.
Posted by David Taylor on March 4, 2010 at 11:55 PM
Another way to remove this is in Lightroom. In the "Detail" tab (where the sharpening & noise reduction settings are), there is a "Chromatic Aberration" panel. Just drag the "Red/Cyan" slider to the position where the fringe disappears. Easy peasy.
Hope this helps.
:toast:
Posted by David Bostedo on March 5, 2010 at 12:19 AM
David - This type of chromatic aberration doesn't always get fixed that way - it's not really the type that ACR/Lightroom is designed for. I did try this one in ACR though and the CA controls didn't do much of anything.
Posted by David Bostedo on March 5, 2010 at 9:43 AM
Actually - I gave what Dave said a little more thought, since I was thinking I should see more effect, even if ACR doesn't fully fix it. Since this is a big crop, I wonder if that was affecting how ACR was trying to fix it.

I'm making some assumptions, but the software probably need to see the whole image captured, with the center of the aberration in the center of the frame in order to properly fix it. So Pete, if you have ACR or Lightroom, it's worth trying the CA sliders. They may fix this better, especially if you have the raw file.
