Snowy Crocus
‹ PreviousWeekly Challenge GalleryNext ›

Snowy Crocus

by Mark Seaver

Gallery: Weekly ChallengePosted November 7, 2012296 views7 comments
This is a 7 image stack of the first Crocus to bloom last winter...too early to call it spring. :smile: The first blooms opened on Jan. 29, which was a new record early. This was Feb. 11, after an overnight snow. It was warm enough that I saw snow crystals "pop" into water drops as I took the stack images. (5D, 100mm macro L, 0.6s, f/22, iso 100, tripod and cable release) Stacked in Helicon Focus and post processed with a TK triple play and some luminosity painting.

Comments

7 comments
Comment posted by Philip Hodgkins on November 7, 2012 at 3:39 PM
Well processed, Mark. An interesting subject and back story! I wonder at the need for stacking at f/22, but I don't question the results.
Registered on July 24, 2006, 2741 Posts, 12349 Comments
Comment posted by Carolyn Derstine on November 7, 2012 at 5:30 PM
Wow, Jan. 29? Well, the weather is getting stranger and stranger. . . Great classic capture of Crocus in the snow, Mark. I like the grouping of the 3 buds at various height levels. Great details from all your stacking. The lighting certainly helps add a cold feel to this image. Brrr!
Registered on February 16, 2011, 610 Posts, 3684 Comments
Comment posted by Mark Seaver on November 7, 2012 at 7:10 PM
Phil, In any stack with overlapping sharp areas there will be artifacts (it's a fundamental law of optics related to the circle of confusion and how things go out of focus). You can minimize these by using an f stop which gets both the front and back areas acceptably sharp. In addition, for macro work like this where I'm approaching 1:1 magnification, depth of field at large apertures, say f/4, is less than a millimeter. This makes it hard to manually adjust your focus while getting overlapping sharp areas from one frame to the next. I use small apertures to give me the best chances of success with well overlapped sharp areas and to minimize artifacts. I've "tested" this lens and camera and found that I cannot see any difference in sharpness for f stops up to f/25. At f/29 and f/32, I don't notice a sharpness loss, but I do see an overall loss of contrast. My experience is backed up by on-line dof calculations showing dof for a 100 mm lens at a focus distance of 15 cm (about 1:1 magnification). These show that the dof at f/4 is +/- 0.1 mm while at f/22 it's +/- 0.5 mm. While I could have opened up to something like f/13, I'd probably not have been successful at f/8 or wider and there would have been a lot more artifacts to clean up in post processing.
Registered on January 23, 2011, 1103 Posts, 17270 Comments
Comment posted by Karen Kane on November 10, 2012 at 2:34 AM
Love the detail you've achieved Mark. I really enjoy the mix of textures between the snow, the water drops and the flower itself.

Also - thank you for the post on stacking and DOF. I had never really heard of stacking (certainly never tried it) before finding NPN and am grateful anytime a process like that is described, as it helps so much!
Registered on August 4, 2012, 66 Posts, 726 Comments
Comment posted by Gary Gulash on November 15, 2012 at 1:32 AM
This is a very beautiful photo Mark. Love the way the purple blends to orange in the crocus. Nice piece of art! Some day I'll have to learn a bit about macro and this stacking technique.
Registered on January 28, 2005, 879 Posts, 12098 Comments
Comment posted by Doug Koepsel on November 15, 2012 at 11:11 AM
Mark, congratulations on the weekly pick. I have no macro lens, yet, so your f-stop discussion was helpful for the future. Seems to be a little ccw lean to the flowers. The phase combo of the snow crystals and the water drops on the petals is nice.
Registered on April 1, 2010, 196 Posts, 1592 Comments
Comment posted by SandyRichardsBrown on November 16, 2012 at 1:34 PM
Congrats on the WP!
Sandy
Registered on November 24, 2003, 3937 Posts, 12909 Comments
